Customized HOWO 5cbm 4tons garbage compactor truck for sale, HOT SALE! Best price rearloaders compress garbage truck

Product Categories
Chengli Special Automobile Co., Ltd.
Contact Now

Customized HOWO 5cbm 4tons garbage compactor truck for sale, HOT SALE! Best price rearloaders compress garbage truck

Brand Name : CLW

Certification : CCC, ISO 9001

Place of Origin : China

MOQ : 1 unit

Price : negotiable

Payment Terms : T/T, L/C

Supply Ability : 20units/month

Delivery Time : 20 days

Packaging Details : in bulk package, waxed

color : different color upon request, free to paint company logo

truck chassis : Chinamade SINO TRUK HOWO diesel truck chassis

price : high quality factory direct sale price

Contact Now

Customized HOWO 5cbm 4tons garbage compactor truck for sale, HOT SALE! Best price rearloaders compress garbage truck

Product name

SINO TRUK HOWO 4*2 LHD 5m3 garbage compactor truck
2 Truck chassis model

ZZ1047
3 Overall dimension(L*W*H)

6760×2190×2540
4 Total mass(kgs) 8280
5 Curb mass(kgs) 5690
6 Rated mass(kgs) 2645
7 Volume 5m3
8 Real loading capacity About 4tons
9 Max speed 95kw/h
10 Wheelbase 3360
11 Axle nos. 2
12 Driver cab SINO 4*2 LHD 2080mm single row driver cab with 2-3 seats
13 Approach/departure angle(°) 19/11
14 Front/rear suspension (mm) 1160/1780
15 Front/rear tread(mm) 1585/1595
16 Tire specification 7.00R16*6
17 Spring 11/11+7
18 Engine model YN4102QBZL
19 Rated power 85KW/116hp
20 Displacement(ml)
3760ml
21 Fuel type Diesel
22 Emission standard Euro Ⅲ
23 Gearbox 6/5 speed gearbox, manual
24 Front/rear axle 2tons/3.5tons
25 Color Different color upon request
26 Wastes van Solid arc-shape box body of strength beam and steel plate welded
27 Wastes van material High quality China standard light duty steel
28 Operation way PLC control way
29 Loading and discharging way Rear overturning mechanism
30 Compacted way Bi-directional compression
31 Wastes compacting density ≥0.8tons/m3
32 One working circle time for loading and discharging ≤30s
33 Max compressing force ≥150KN
34 Max passing force ≥180KN
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of garbage trucks in China since 2004s. With many years' experience in developing, Chengli Special Automobile Co., Ltd. could supply garbage compactor truck, refuse garbage truck, swing arm garbage truck, skid loader garbage truck, side loader garbage truck, sealed garbage truck, dump garbage truck, etc. More information, please feel free to contact Ms. Anita Deng.

Website: www.trucksinchina.com

Whatsapp/Mob./Wechat: 0086 13329899995

Email: truck0011@163.com; chenglitruckanita@hotmail.com; clwtrucks2020@gmail.com

Customized HOWO 5cbm 4tons garbage compactor truck for sale, HOT SALE! Best price rearloaders compress garbage truck

Customized HOWO 5cbm 4tons garbage compactor truck for sale, HOT SALE! Best price rearloaders compress garbage truck

1. Concept: The waste collection and transportation system of five-chemical treatment technology is composed of
environmentally-friendly deep-buried trash cans and special hook-arm compression box trucks, and is a landfill designed with mature technologies in western developed countries. As a garbage collection container, the smart garbage collection bin is a new type of collection and transportation mode in which garbage compression garbage trucks are directly transported to the garbage disposal point. The environmentally-friendly deep-buried bucket collection and transportation system integrates the functions of deep-buried bucket hoisting, garbage collection, garbage transportation, and pollution absorption. It is a revolution in the domestic garbage collection and transportation mode. It can effectively solve the bottleneck of domestic urban and rural garbage collection and transportation, especially in terms of urban-rural integration and beautiful rural construction.
2. Features: unattended, large collection of single-bin garbage, low operating costs, and high environmental protection.
3. Effectiveness: effective solution
1. Concept:
"LJ" waste collection and transportation system with five chemical processing technology,composed of
environmentally-friendly deep-buried waste bins, special hook-arm compression box trucks, and landfill smart waste designed with
mature technologies in western developed countries The collection bucket is a new type of collection and transportation mode in
which the garbage collection container is directly transported to the garbage disposal point by hoisting the garbage compression
garbage truck. The environmentally-friendly deep-buried bucket collection and transportation system integrates the functions of
deep-buried bucket hoisting, garbage collection, garbage transportation, and pollution absorption. It is a revolution in the
domestic garbage collection and transportation mode. It can effectively solve the bottleneck of domestic urban and rural garbage
collection and transportation, especially in terms of urban-rural integration and beautiful rural construction.
2. Features:
unattended, large collection of single-bin garbage, low operating costs, and high environmental
protection.
3. Efficiency:
Effectively solve the bottleneck of domestic urban and rural garbage collection and transportation.
Especially the integration of urban and rural areas and the construction of beautiful villages have unique effects.
4. Applicable:
Towns, villages, scenic spots, parks, schools, stadiums and other areas with moderate amount of garbage, suitable
for building garbage transfer stations, and high environmental requirements. .

Wholesale Customized HOWO 5cbm 4tons garbage compactor truck for sale, HOT SALE! Best price rearloaders compress garbage truck from china suppliers
